Possible issues caused by this broken part:
- Agilent 6890N GC doesn’t work.
- Agilent 6890N GC doesn’t turn on.
- Agilent 6890N GC shuts down.
Possible errors prompted by this broken part:
GC Control Panel:
- Fault 203 – Signal DSP faulty
- Fault 204 – Sig DSP ROM broken
- Fault 205 – Sig DSP RAM broken
- Fault 206 – Sig DSP registers
- Fault 207 – Sig DSP data corrupt
- Fault 208 – 0-1 mV out # 1
- Fault 209 – 0-1 mV out # 2
- Fault 210 – Analog out # 1
- Fault 211 – Analog out # 2
- Fault 221 – Thermal shutdown
- Fault 222 – Oven temp too hot
- Fault 225 – F det temp too hot
- Fault 227- B det temp too hot
- Fault 229 – F inl temp too hot
- Fault 231 – B inl temp too hot
- Fault 233 – Aux l temp too hot
- Fault 235 – Aux 2 temp too hot
- Fault 237 – No line interrupt
- Fault 238 – Line interrupt
- Fault 239 – No mux ADC response
- Fault 240 – Mux ADC offset value
- Fault 241 – Invalid line sense
- Fault 262 – RS232 defective
- Fault 263 – GPIB (or HP-IB) defective
- Fault 264 – Sampler RS232 defect
- Main FPGA Failure
- Main FPGA Failure
- Boot ROM Checksum
- DMA FPGA Failure
- DRAM Failure
- Exception Vector
- Bus Error
- Address Error
- Illegal Instruction
- Divide by Zero
- No 512Hz Interrupt
